Résumé

Most of the World’s platinum-group element ore deposits occur as thin stratiform layers within layered intrusions. These layers generally contain disseminated base-metal sulfides or chromite. However, cryptic platinum-group element deposits also occur without chromite or base-metal sulfides in what are known as low-S-high platinum-group element deposits. The origin of these deposits is not clearly understood. The Luanga Complex hosts the largest platinum-group elements resource in South America (i.e., 142 Mt at 1.24 ppm Pt þ Pd þ Au and 0.11% Ni) and hosts both a platinum-group element deposit containing disseminated base-metal sulfides (style 1) and a low-S-high platinum-group element deposit (style 2). It therefore offers the opportunity to compare the two deposit types in the same overall geological setting and consider how the low-S-high platinum-group element deposit could have formed. The first deposit style is termed the Sulfide zone and consists of a 10–50 meter-thick interval with disseminated base metal sulfides, whereas the second style is named low-S-high-Pt-Pd zone and consists of 2–10 meter-thick discontinuous lenses of 1–5 meter-thick sulfide- and oxide-free harzburgite and orthopyroxenite with discrete platinum-group minerals. Secondary assemblages commonly replace primary igneous minerals to a variable extent throughout the deposit, and thus allow for investigating the effects of post-cumulus alteration on the distribution of a wide range of chalcophile elements in a magmatic sulfide deposit at both whole-rock and mineral scale. This study presents the whole-rock distribution of S, platinum-group elements, and Te, As, Bi, Sb, and Se in both mineralization styles and the concentration of trace elements in base-metal sulfides from the Sulfide zone. The Sulfide zone has Pt/Pd ratios around 0.5 and high concentrations of Te, As, Bi, Sb, and Se, whereas the low-S-high-platinum-group element zone has Pt/Pd ratios greater than 1 and much lower Se, Te, and Bi concentrations, but comparable As and Sb contents. This is reflected in the platinum-group element assemblage, comprising bismuthotellurides in the Sulfide zone and mostly arsenides and antimonides in the low-S, high platinum-group elements zone. Moreover, the base-metal sulfides from the Sulfide zone have anomalously high As contents (50–500 ppm), which suggest that the sulfide liquid segregated from a very As-rich silicate magma, possibly illustrated by an average komatiitic basalt that assimilated a mixture of upper continental crust and black shales. We interpret the low-S- high platinum-group elements zone as a product of S loss from magmatic sulfides during post-cumulus alteration of the Luanga Complex. Selenium, Te, Bi, and Pd were also lost together with S, whereas As and Sb were expelled from base-metal sulfide structures and combined with platinum-group elements to form platinum-group minerals, suggesting they may play a role fixating platinum-group elements during alteration. The remobilization of chalcophile elements from magmatic sulfide deposits located in the Caraja ́s Mineral Province may represent a potential source for hydrothermal deposits found in the region.
